Integrated Dynamics Hawk MK V Unmanned Aerial Vehicle System (UAVS):

Integrated Dynamics is a well-known and well-reputed company of PAKISTAN engaged in the designing and manufacturing of state of the art Unmanned Aerial Vehicle Systems (UAVS) for both Military and Civilian purposes. The name of the new UAVS introduced by the company known as Integrated Dynamics Hawk MK V Unmanned Aerial Vehicle System (UAVS).

PAKDEFENSE Hawk MK V UAVS

The Integrated Dynamics Hawk MK V Unmanned Aerial Vehicle System (UAVS) is basically a long-range Tactical Surveillance Unmanned Aerial Vehicle System (UAVS). The Integrated Dynamics Hawk MK V Unmanned Aerial Vehicle System (UAVS) is a multi-mission UAVS and it can easily be used for the surveillance of the area ranges from 80 – 120 Kilometers.
The Integrated Dynamics Hawk MK V Unmanned Aerial Vehicle System (UAVS) is powered by the powerful engine varies from 15-25 British Horse Power (bhp) engine. The Integrated Dynamics Hawk MK V Unmanned Aerial Vehicle System (UAVS) comes with the 4.25 meter (14 ft) wingspan that allows the user to install a variety of Payloads as a visible color video system, infrared low light cameras and still cameras.

Hawk MK V UAVS PAKDEFENSE

The Integrated Dynamics Hawk MK V Unmanned Aerial Vehicle System (UAVS) rigorous testing and proven multi-mission capabilities in a different series of field trials from different surveillance platforms, aerial targets and experimental electronic payload test-beds. The company also combined the UAVS with the unique Military Standard C4I system at an unbelievable affordable level.
The Integrated Dynamics Hawk MK V Unmanned Aerial Vehicle System (UAVS) is crafted from the aerospace quality composite material and field-proven airframes for reliability and durability of the UAVS. The refined aerodynamics of the Hawk MK V allow extended loiter aerial operations over designated targets.

Hawk MK V UAVS

The pre-programmed Smart Flight feature of the Hawk MK V also help to significantly reduce the UAV’s survivability and it also reduces the operator workload time
The refined aerodynamics and low-radar signature also allow for extended operations with minimal chances of detection. The Integrated Dynamics Hawk MK V Unmanned Aerial Vehicle System (UAVS)is equipped with the latest GPS Navigation System and it is also housed with microelectronic flight control that can be readied for operation in a short notice.

Technical Specifications of the Integrated Dynamics Hawk MK V Unmanned Aerial Vehicle System (UAVS):

  1. Role: Tactical Surveillance Unmanned Aerial Vehicle System (UAVS)
  2. Total Area of Wing: 3.09 Sq. m (30 sq. ft)
  3. Wingspan: 4.51 meter (14 ft)
  4. Total Length of UAVS: 2.95 meters (9 ft 8 inches)
  5. Total Height of UAVS: -0.89 meter (2 Ft. 7 Inches)
  6. Total Empty Weight: 25 Kilograms (55 lbs)
  7. Takeoff Weight: 65 Kilograms (143 lbs)
  8. Total Range of Speed: 132-240 kmph (70-150 mph)
  9. Total Fuel Capacity: 25 liters (Max.)
  10. Power Plant: 22 British Horse power Twin-Cylinder Piston Engine
  11. GPS/Autonomous Range: 100 Kilometers (60 Miles)
  12. Recovery Method: Parachute or Wheel
  13. Total Payload Capacity: 15 Kilograms (33 lbs)
  14. Typical Payloads: EO/IR Payloads and GSP-900 Surveillance real-time Camera Modules
  15. Stabilization: IFCS-6000 Integrated Flight Control System
  16. Tracking & Telemetry: ATPS-2000 Antenna Tracking System, GCS-2000 Ground Control Station and ID-TM6 GPS and Data Telemetry Module
